RMK
A feature-rich Rust keyboard firmware.
Features
- Support a wide range of microcontrollers: Powered by embassy, RMK supports a wide range of microcontrollers, such as stm32/nrf/rp2040
- Real-time keymap editing: Keyboard layout can be customized at the compile-time with real-time keymap editing using vial
- Advanced keyboard features: Many advanced keyboard features are available by default in RMK, such as layer switch, media control, system control, mouse control, etc
- Wireless: (Experimental) BLE wireless support with auto-reconnection/multiple devices feature for nrf52 microcontrollers, tested on nrf52840
News
-
[2024.03.07] BLE support with auto-reconnection/multiple devices feature for nrf52840/nrf52832 has beed added to RMK! Checkout boards/nrf52840_ble and boards/nrf52832_ble for details.
-
[2024.02.18] Version
0.1.4
is just released! This release contains a new build script for generating vial config, minor API update and a brand new user documentation page.
Click to checkout more news
-
[2024.01.26] 🎉rmk-template is released! Now you can create your own keyboard firmware with a single command:
cargo generate --git https://github.com/HaoboGu/rmk-template
-
[2024.01.18] RMK just released version
0.1.0
! By migrating to Embassy, RMK now has better async support, more supported MCUs and much easier usages than before. For examples, checkboards
folder!
User Documentation
API Reference
Usage
Option 1: Initialize from template
You can use rmk-template to initialize your project.
cargo install cargo-generate
cargo generate --git https://github.com/HaoboGu/rmk-template
Then follow the steps in generated README.md
. Check RMK's User Guide for details.
Option 2: Try built-in examples
Example can be found at boards
. The following is a simple
step-to-step instruction for rp2040 and stm32h7
rp2040
-
Install probe-rs
cargo install probe-rs --features cli
-
Build the firmware
cd boards/rp2040 cargo build
-
Flash
If your rp2040 board is connected with a debugging probe, just use the following command to flash RMK firmware to the board:
cd boards/rp2040 cargo run
If you don't have a debugging probe, you can use
elf2uf2-rs
to flash your firmware via USB. There are several additional steps you have to do:- Install
elf2uf2-rs
:cargo install elf2uf2-rs
- Update
boards/rp2040/.cargo/config.toml
, useelf2uf2
as the flashing tool- runner = "probe-rs run --chip RP2040" + runner = "elf2uf2-rs -d"
- Connect your rp2040 board holding the BOOTSEL key, ensure that rp's USB drive appears
- Flash
Then, you will see logs like if everything goes right:cd boards/rp2040 cargo run
Finished release [optimized + debuginfo] target(s) in 0.21s Running `elf2uf2-rs -d 'target\thumbv6m-none-eabi\release\rmk-rp2040'` Found pico uf2 disk G:\ Transfering program to pico 173.00 KB / 173.00 KB [=======================] 100.00 % 193.64 KB/s
- Install
stm32h7
-
Install openocd
-
Build the firmware
cd boards/stm32h7 cargo build
-
Flash
Make sure you have a debugging probe connected to your board. You can use both
probe-rs
andopenocd
to flash the firmware:# Use openocd openocd -f openocd.cfg -c "program target/thumbv7em-none-eabihf/debug/rmk-stm32h7 preverify verify reset exit" # Use probe-rs cd boards/stm32h7 cargo run
-
(Optional) Debug firmware using CMSIS-DAP
Open the project using VSCode, choose
Cortex-Debug - stm32h7
debug profile, then pressF5
, the firmware will be automatically compiled and flashed. A debug session is started after flashing. Check.vscode/tasks.json
and.vscode/launch.json
for details.
Roadmap
Current roadmap of RMK can be found here.
Minimum Supported Rust Version (MSRV)
This crate requires stable Rust 1.75 and up.
License
RMK is licensed under either of
- Apache License, Version 2.0 (LICENSE-APACHE or http://www.apache.org/licenses/LICENSE-2.0)
- MIT license (LICENSE-MIT or http://opensource.org/licenses/MIT)
at your option.
