debugchrome-cdp-rs
debugchrome-cdp-rs
introduces a command debugchrome
and a custom windows protocol, debugchrome:
and debugchrome://
. It is currently windows only.
When using default protocol handlers, the url opens in the default browser. There is no cross platform way to interact with the programs that launch or the documents themselves after launch. Url invocation gives you no way to interrogate the system to determine what exact tab and program the user is interacting with.
Using something like open, cmd /c start, open::that the default application runs but there are no great ways to query/interact with that unknown servicing application and document.
Sometimes default handlers aren't set, other times the api may return incorrect results, or the browser just doesn't open as it should. #73 It's unreliable like udp; chromedebug
helps make default open more reliable by providing mechanisms to query and control past the point of open.
debugchrome
is a program and protocol handler designed to open a http(s) url in a --remote-debugging-port=9222 chrome browser.
The protocol works if you specify debugchrome:
or debugchrome://
before your url and add the !bang variables at the end of your query to control operation.
Features
-
Open a url (brought to front and at location on screen):
- Opens a specified URL with optional window placement / bounds (
!x
,!y
,!w
,!h
). - Example:
debugchrome:https://www.rust-lang.org?!x=0&!y=0&!w=800&!h=600
- Window bounds can be expressed as a percentage and relative to a monitor
- Example:
debugchrome://https://www.rustlang.org?!x=12.5%&!y=12.5%&!w=75%&!h=75%&!monitor=2
- Opens a specified URL with optional window placement / bounds (
-
Set
id
:- Sets a custom
id
in the tab's JavaScript context(session storage so it persists refresh) using the!id
parameter in the URL. - Example:
debugchrome:https://www.rust-lang.org?x=0&y=0&w=800&h=600&!id=123
- This Id is used to annotate the url with an ID that can be used to find and interact with the tab.
- Sets a custom
-
Timeout:
debugchrome
will wait for the specified number of seconds and then search and close the page automatically.- Example:
debugchrome://https://crates.io/crates/debugchrome-cdp-rs?!timeout=5
-
Keep Focus
- Add a !keep_focus parameter in the url and the window that is currently active will be re-focused after the page is loaded.
- Example:
debugchrome://https://crates.io/crates/debugchrome-cdp-rs?!id=21jump&!keep_focus
This allows you to launch a url from cmd or powershell and not have the webpage take focus away from the terminal.
-
Take a Screenshot:
- Captures a screenshot of the page and opens the default viewer for
.png
. - Example:
debugchrome:https://www.rust-lang.org?x=0&y=0&w=800&h=600&!id=123&!screenshot
- Captures a screenshot of the page and opens the default viewer for
-
Search for Tabs by
bangId
:- Searches all open tabs for a specific
bangId
and prints the matching tab's URL.
- Searches all open tabs for a specific
-
Register Custom Protocol:
- Registers the
debugchrome:
protocol in the Windows registry for easier usage.
- Registers the
Usage
Prefix any url with debugchrome:
and that url will be processed by debugchrome.
The protocol begins debugchome:
then your url, followed by ! bang parameter variables. In other words, all parameters operated on by debugchrome
are assumed to be appended to the end of the url (not interdispersed) and the variables debugchrome deals with begin with the !. This makes it easy to determine the clean url and limits clashing with existing variables.
debugchome addresses common challenges such as controlling the location of the browser window, determining if a url is open, closing a tab, setting custom data (bangId
) in the JavaScript context, and even capturing screenshots. By using the debugchrome:
protocol, you've got a way to position, query, and control default document open.
1. Register the debugchrome:
Protocol
If you want to use debugchrome:\\
urls, you will first need to register the path to the executable in the windows registry.
debugchrome.exe --register
- Writes a debugchrome.reg file next to the debugchrome.exe (typically in your .cargo/bin)
- Registers the
debugchrome:
protocol in the Windows registry (given permissions). - Allows you to use
debugchrome:
URLs directly.
2. Open a url
debugchrome.exe "debugchrome:https://www.rustlang.org?!x=0&!y=0&!w=800&!h=600"
- Opens a specified URL.
- add any of ! query parameters:
!x
: X-coordinate of the window.!y
: Y-coordinate of the window.!w
: Width of the window.!h
: Height of the window.- etc
3. Set id
debugchrome.exe "debugchrome:https://www.rustlang.org?!x=0&!y=0&!w=800&!h=600&!id=123"
- Sets
window.bangId
in the tab's JavaScript context to123
.
4. Search for page by id
debugchrome.exe --search 123
- Searches all open tabs for a tab where
window.bangId
is123
. - Prints the matching tab's URL if found.
5. Take a Screenshot
debugchrome.exe "debugchrome:https://www.rust-lang.org!screenshot"
- Captures a screenshot of the tab and opens the default viewer for the screenshot.
6. Keep Focus
debugchrome.exe "debugchrome:https://www.rust-lang.org?!keep_focus"
- Ensures the window that was in focus at time of open is the window that remains in focus on exit.
7. Close a Tab
debugchrome.exe --search 123 --close
- Searches for the tab with the specified
bangId
and closes it. - Example:
debugchrome.exe --search 123 --close
will close the tab wherewindow.bangId
is123
. - Note: The
!id
parameter must be specified when opening the tab to use this feature. - Note: Specifying
!close
without an!id
will not close, if you specify close and the page isn't found, the page will be opened. The same url with the!close
specified, will then close the page when opened again. - Example:
debugchrome.exe "debugchrome:https://www.rust-lang.org!id=1&!close&!openwindow&!keep_focus"
will open and close a window without taking focus.
8. Refresh a Tab
debugchrome.exe --search 123 [--close]
- Searches for the tab with the specified
id
and activates it. If !refresh is specified on the url, the page will be refreshed after being activated. - Example:
debugchrome.exe --search 123 --close
will close the page wherewindow.bangId
is123
. - Example:
debugchrome.exe "debugchrome:https://www.rust-lang.org?!refresh"
will close the page after 10 seconds. - Note: The
!id
parameter must be specified when opening the tab to use this feature.
9. Set Timeout
debugchrome.exe "debugchrome:https://www.rust-lang.org?!timeout=10"
- Sets a timeout (in seconds) for the tab to remain open.
- Example:
debugchrome.exe "debugchrome:https://www.rust-lang.org?!timeout=10"
will close the page after 10 seconds.
10. Specify Monitor
debugchrome.exe "debugchrome:https://www.rust-lang.org?!monitor=2"
- Opens the tab on a specific monitor.
- Example:
debugchrome.exe "debugchrome:https://www.rust-lang.org?!monitor=2"
will open the tab on monitor 2. - Monitor indices start from 0.
11. Open Window
debugchrome.exe "debugchrome:https://www.rust-lang.org?!openwindow"
- Opens the url as a new window instead of as a tab.
- Example:
debugchrome.exe "debugchrome:https://www.rust-lang.org?!openwindow"
will open the url in a new window.
Sample CLI
-
Open a url using cli:
debugchrome.exe "debugchrome:https://www.rustlang.org?!x=0&!y=0&!w=800&!h=600&!id=456"
-
Search for a page by id using cli:
debugchrome.exe --search 456
-
Register the Protocol using cli:
debugchrome.exe --register
How It Works
You can run a debug browser and open things in there to get programatic access to your tab information; you need a protocol handler installed to allow default open urls into that debugger enabled environment.
Opening a url
- Uses the
Target.createTarget
CDP method to open a new tab with the specified URL. - Optionally sets window bounds using
Browser.setWindowBounds
.
Setting bangId
- Parses the
!id
parameter from the URL. - Uses the
Runtime.evaluate
CDP method to setwindow.bangId
in the tab's JavaScript context.
Taking a Screenshot
- Enables the
Page
domain usingPage.enable
. - Captures a screenshot using
Page.captureScreenshot
. - Saves the screenshot as
.
Searching for Tabs
- Fetches all open tabs using the
http://localhost:9222/json
endpoint. - Connects to each tab's WebSocket and evaluates
window.bangId
usingRuntime.evaluate
. - Matches the
bangId
with the search query.
Registering the Protocol
- Writes a
.reg
file to register thedebugchrome:
protocol in the Windows registry. - Allows you to use
debugchrome:
URLs directly.
Example Output
Output is minimal to stdout; detailed output can be found in %USERPROFILE%\.cargo\bin\debugchrome.log
or next to wherever debugchrome
lives. The same is true for the screenshots; it saves a single %USERPROFILE%\.cargo\bin\debugchome.png
/ & "$env:USERPROFILE\.cargo\bin\debugchrome.png"
or next to the executable. Sorry for the loose files in bin, at least they all start with debugchrome; this may change in the future. Chrome profile folders are kept in %TEMP%\ starting with debugchrome.
Notes
-
Dependencies:
- Ensure that Chrome is running with the
--remote-debugging-port=9222
flag. If it's not running, it will attempt to start it for you.
- Ensure that Chrome is running with the
-
Skipped Tabs:
- Tabs with URLs starting with
ws://
,chrome-extension://
,chrome://
, ,about:
,data:
,view-source:
,devtools://
, orchrome-devtools://
are skipped during the search.
- Tabs with URLs starting with
-
It's not fast:
- If you need to scan 400 tabs; it is going to take some time.
License
This project is licensed under the MIT License. David Horner 5/25
