bevy_play_card

A card crate for the Bevy game engine

Using The Crate (link)

Change Logs (link)

Use Examples (link)

Tween Priorities To Others Of Type (link)

Bevy Version Support

Credits

• bevy_tween The crate this one is built upon. Thanks to it I was able to set this crate up rather quickly and easily.

lib.rs:

Using The Crate

(Click me to go back to the main readme)

Registering the Plugin

First, you should add BevyCardPlugin, it has a ::default() implementation but can be reconfigured, for example:

app.add_plugins(
BevyCardPlugin {
card_hover_height: 40.0,
..default()
},
);

Spawning Cards

The basic functionality derived from Bevy Picking is added to Cards automatically. It's recommended to instantiate a card using card bundles:

commands.spawn((
CardBundle::new(Transform::default()),
Sprite {
image: asset_server.load("your card sprite path here"),
..default ()
},
));

Cards are named automatically by the card_namer. When the Card component is removed from an entity, it's automatically removed from it's owner line if it had any.

Spawning Card Lines

Cards can live on a card line, that'll allow you to reorder them and keep them neatly organized. All you need to instantiate a card line is:

commands
.spawn(CardLineBundle::from_transform(Transform::default()));

Or more specifically using from_card_line:

commands
.spawn(CardLineBundle::from_card_line(
CardLine::default()
.with_origin(
Transform::from_translation(location.into())
.with_rotation(Quat::from_rotation_z(rotation)),
)
.with_max_cards(MAX_CARDS)
.with_card_origin_gap(60.0),
));

Using Card Line Requests

Although you could interact with the entities directly, you can spare yourself some boilerplate by firing events using EventWriter<CardLineRequest>, already listened to by the plugin. Each CardLineRequest contains the entity of the line to which it'll be applied and a request type with relevant additional data if there's any. The variants of CardLineRequestType are as follows:

Card Tags

Cards are being tagged for easier queries when they're hovered, picked and dragged. Hovered and Dragged are removed once the status is done, Picked is toggled by clicking. This way you can, for example, get all hovered card with queries like: Query<&Card, With<Hovered>>

For use examples, see using_card_tags.rs

Workflow Example

Let's spawn a line and add a few cards to it, see cards_on_a_line.rs for another example of that scenario.

First, let's spawn a defaultly-configured line in the middle of the screen.

let line_entity = commands
.spawn(CardLineBundle::from_transform(Transfrom::default())).id();

Now, let's spawn three cards, sending a request to add each to a line. Sending the requests separately ensures the line stays within capacity, leaving out the last cards to be spawned if any. The shape of the loop is as follows:

for _ in 0..3 {
let card_entity = commands.spawn(( ... )).id();
card_line_request_writer.write(CardLineRequest { ... });
}

An example for card spawning would be:

let card_entity = commands
.spawn((
Sprite {
image: asset_server.load("path to your card sprite here"),
..default()
},
CardBundle::new(Transform::default()),
)).id();

With the appropriate addition request:

card_line_request_writer.write(CardLineRequest {
line: line_entity,
request_type: CardLineRequestType::AddToLine { card_entity },
});

Ending up with:

let line_entity = commands
.spawn(CardLineBundle::from_transform(Transfrom::default())).id();
for _ in 0..3 {
let card_entity = commands
.spawn((
Sprite {
image: asset_server.load("path to your card sprite here"),
..default()
},
CardBundle::new(Transform::default()),
)).id();
card_line_request_writer.write(CardLineRequest {
line: line_entity,
request_type: CardLineRequestType::AddToLine { card_entity },
});
}

(Click me to go back to the main readme)
