rbatis

Rust ORM Framework High Performance高性能Rust ORM框架(JSON based)

30 stable releases

new 1.4.3 Aug 10, 2020
1.4.2 Aug 7, 2020
1.3.7 Jul 30, 2020
1.1.5 Jun 30, 2020
1.0.7 Feb 29, 2020

#47 in Memory management

Download history 5/week @ 2020-04-21 2/week @ 2020-04-28 15/week @ 2020-05-12 6/week @ 2020-05-26 15/week @ 2020-06-02 3/week @ 2020-06-09 5/week @ 2020-06-16 55/week @ 2020-06-23 93/week @ 2020-06-30 39/week @ 2020-07-07 65/week @ 2020-07-14 116/week @ 2020-07-21 116/week @ 2020-07-28 29/week @ 2020-08-04

185 downloads per month

MIT license

205KB
4.5K SLoC

A ORM formwork Rustlang-based,dynamic sql, no Runtime,No Garbage Collector, low Memory use,High Performance orm Framework. support async_std,tokio

rbatis 是一个无GC无虚拟机无运行时Runtime直接编译为机器码,并发安全的 数据库 ORM框架,并且所有数据传值均使用json(serde_json)

rbatis 使用百分之百的安全代码实现

This crate uses #![forbid(unsafe_code)] to ensure everything is implemented in 100% Safe Rust.

Build Status

Image text

way not diesel,way not sqlx ? 为什么不选择diesel,sqlx之类的框架?
框架 协程异步async高并发 使用难度 符合企业化规范(支持xml,无需重复编译) logic del逻辑删除插件 page分页插件
rbatis 简单(依赖json和反射)
sqlx 难(依赖宏) x x x
diesel x 简单(缺少xml支持) x x x
和其他语言对比性能压测(环境(docker)仅供参考)
语言 框架 数据库 查询语句 纳秒/每操作(低越好) 查询数/秒Qps(高越好) 内存(低越好)
Rust rbatis - tokio Runtime mysql(docker with 1CPU,1G Mem) select count(1) from table; 10000次 965649 ns/op 1035 Qps/s 2.1MB
Golang GoMybatis - goroutines mysql(docker with 1CPU,1G Mem) select count(1) from table; 10000次 1184503 ns/op 844 Qps/s 28.4MB
  • 使用最通用的json数据结构(基于serde_json)进行传参和通讯
  • 高性能,单线程benchmark 可轻松拉起200000 QPS/s(直接返回数据(数据库查询时间损耗0),win10,6 core i7,16GB) 多线程更高 远超go语言版本的GoMyBatis
  • 多功能,乐观锁插件+逻辑删除插件+分页插件+Py风格Sql+基本的Mybatis功能
  • 支持future,async await(理论上,假设严格按照async_std/tokio库替代所有io操作,那么并发量可远远超过go语言)
  • 日志支持,可自定义具体日志(基于标准库log(独立于任何特定的日志记录库),日志可选任意第三方库实现)
  • 使用百分百的安全代码实现(lib.rs加入了"#![forbid(unsafe_code)]" 禁止不安全的unsafe代码)
  • 点击查看-示例代码(建议用Clion导入项目而不是VSCode以支持debug)
项目实战例子 https://github.com/rbatis/abs_admin
首先(Cargo.toml)添加项目依赖
# add this library,and cargo install

#json支持
serde = { version = "1.0", features = ["derive"] }
serde_json = "1.0"

#log日志支持
log = "0.4"
fast_log="1.2.2"

#rbatis-core和rbatis 版本必须保持一致
rbatis-core = { version = "1.4.3", features = ["all"]}
rbatis =  { version = "1.4.3" }
基本的CRUD内置方法 save,save_batch,remove_batch_by_id,list_by_ids...等等常用方法(详见 example/crud_test.rs)
let activity = Activity {
                id: Some("12312".to_string()),
                name: None,
                remark: None,
                create_time: Some(NaiveDateTime::now()),
                version: Some(1),
                delete_flag: Some(1),
            };
 let r = rb.save("",&activity).await;
            if r.is_err() {
                println!("{}", r.err().unwrap().to_string());
            }
QueryWrapper支持,可以免写xml,py,sql(详见 example/crud_test.rs)
 let mut m = Map::new();
        m.insert("a".to_string(), json!("1"));
        let w = Wrapper::new(&DriverType::Mysql).eq("id", 1)
            .and()
            .ne("id", 1)
            .in_array("id", &[1, 2, 3])
            .not_in("id", &[1, 2, 3])
            .all_eq(&m)
            .like("name", 1)
            .or()
            .not_like("name", "asdf")
            .between("create_time", "2020-01-01 00:00:00", "2020-12-12 00:00:00")
            .group_by(&["id"])
            .order_by(true, &["id", "name"])
            .check().unwrap();
分页插件使用
        let rb = Rbatis::new();
        rb.link(MYSQL_URL).await.unwrap();
        let wraper= rb.new_wrapper().eq("delete_flag",1).check().unwrap();
        let data: Page<BizActivity> = rb.fetch_page_by_wrapper("", &wraper,  &PageRequest::new(1, 20)).await.unwrap();
        println!("{}", serde_json::to_string(&data).unwrap());

2020-07-10T21:28:40.036506700+08:00 INFO rbatis::rbatis - [rbatis] Query ==> SELECT count(1) FROM biz_activity  WHERE delete_flag =  ? LIMIT 0,20
2020-07-10T21:28:40.040505200+08:00 INFO rbatis::rbatis - [rbatis] Args  ==> [1]
2020-07-10T21:28:40.073506+08:00 INFO rbatis::rbatis - [rbatis] Total <== 1
2020-07-10T21:28:40.073506+08:00 INFO rbatis::rbatis - [rbatis] Query ==> SELECT  create_time,delete_flag,h5_banner_img,h5_link,id,name,pc_banner_img,pc_link,remark,sort,status,version  FROM biz_activity  WHERE delete_flag =  ? LIMIT 0,20
2020-07-10T21:28:40.073506+08:00 INFO rbatis::rbatis - [rbatis] Args  ==> [1]
2020-07-10T21:28:40.076506500+08:00 INFO rbatis::rbatis - [rbatis] Total <== 5
{
	"records": [{
		"id": "12312",
		"name": "null",
		"pc_link": "null",
		"h5_link": "null",
		"pc_banner_img": "null",
		"h5_banner_img": "null",
		"sort": "null",
		"status": 1,
		"remark": "null",
		"create_time": "2020-02-09T00:00:00+00:00",
		"version": 1,
		"delete_flag": 1
	}],
	"total": 5,
	"size": 20,
	"current": 1,
	"serch_count": true
}
py风格sql语法Example
//执行到远程mysql 并且获取结果。支持serde_json可序列化的任意类型
         let rb = Rbatis::new(MYSQL_URL).await.unwrap();
            let py = r#"
        SELECT * FROM biz_activity
        WHERE delete_flag = #{delete_flag}
        if name != null:
          AND name like #{name+'%'}
        if ids != null:
          AND id in (
          trim ',':
             for item in ids:
               #{item},
          )"#;
            let data: serde_json::Value = rb.py_fetch("", py, &json!({   "delete_flag": 1 })).await.unwrap();
            println!("{}", data);

日志系统(这里举例使用fast_log)

 //main函数加入
 use log::{error, info, warn};
 fn  main(){
      fast_log::log::init_log("requests.log", &RuntimeType::Std).unwrap();
      info!("print data");
 }

自定义连接池大小,超时,活跃连接数等等

use rbatis_core::db::PoolOptions;

pub async fn init_rbatis() -> Rbatis {
let rb = Rbatis::new();
let mut opt = PoolOptions::new();
opt.max_size = 20;
rb.link_opt("mysql://root:123456@localhost:3306/test", &opt).await.unwrap();
}

xml使用方法

/**
* 数据库表模型
*/
#[derive(Serialize, Deserialize, Debug, Clone)]
pub struct Activity {
    pub id: Option<String>,
    pub name: Option<String>,
    pub pc_link: Option<String>,
    pub h5_link: Option<String>,
    pub pc_banner_img: Option<String>,
    pub h5_banner_img: Option<String>,
    pub sort: Option<String>,
    pub status: Option<i32>,
    pub remark: Option<String>,
    pub create_time: Option<NaiveDateTime>,
    pub version: Option<i32>,
    pub delete_flag: Option<i32>,
}
fn main() {
    async_std::task::block_on(
           async move {
               fast_log::log::init_log("requests.log", &RuntimeType::Std).unwrap();
               let mut rb = Rbatis::new();
               rb.link(MYSQL_URL).await.unwrap();
               //xml数据建议以 XXMapper.xml 的格式存储管理
               rb.load_xml("test", r#"<?xml version="1.0" encoding="UTF-8"?>
   <!DOCTYPE mapper PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN"
           "https://raw.githubusercontent.com/zhuxiujia/Rbatis/master/rbatis-mapper.dtd">
   <mapper>
       <result_map id="BaseResultMap" table="biz_activity">
           <id column="id"/>
           <result column="name" lang_type="string"/>
           <result column="pc_link" lang_type="string"/>
           <result column="h5_link" lang_type="string"/>
           <result column="pc_banner_img" lang_type="string"/>
           <result column="h5_banner_img" lang_type="string"/>
           <result column="sort" lang_type="string"/>
           <result column="status" lang_type="number"/>
           <result column="remark" lang_type="string"/>
           <result column="version" lang_type="number" version_enable="true"/>
           <result column="create_time" lang_type="time"/>
           <result column="delete_flag" lang_type="number" logic_enable="true" logic_undelete="1"
                   logic_deleted="0"/>
       </result_map>
       <select id="select_by_condition">
           <bind name="pattern" value="'%' + name + '%'"/>
           select * from biz_activity
           <where>
               <if test="name != null">and name like #{pattern}</if>
               <if test="startTime != null">and create_time >= #{startTime}</if>
               <if test="endTime != null">and create_time &lt;= #{endTime}</if>
           </where>
           order by create_time desc
           <if test="page != null and size != null">limit #{page}, #{size}</if>
       </select>
   </mapper>"#).unwrap();

               let arg = &json!({
               "delete_flag": 1,
               "name": "test",
               "startTime": null,
               "endTime": null,
               "page": 0,
               "size": 20
               });
               let data: Vec<Activity> = rb.xml_fetch("", "test", "select_by_condition", arg).await.unwrap();
               println!("{}", serde_json::to_string(&data).unwrap_or("".to_string()));
           }
       )
}
//输出结果
//2020-06-27T03:13:40.422307200+08:00 INFO rbatis::rbatis - [rbatis] >> fetch sql: select * from biz_activity where name like  ? order by create_time desc limit  ? ,  ?   (src\rbatis.rs:198)
//2020-06-27T03:13:40.424307300+08:00 INFO rbatis::rbatis - [rbatis] >> fetch arg:["%test%",0,20]  (src\rbatis.rs:199)
//2020-06-27T03:13:40.446308900+08:00 INFO rbatis::rbatis - [rbatis] << 4  (src\rbatis.rs:234)
//[{"id":"221","name":"test","pc_link":"","h5_link":"","pc_banner_img":null,"h5_banner_img":null,"sort":"0","status":0,"remark":"","create_time":"2020-06-17T20:10:23Z","version":0,"delete_flag":1},{"id":"222","name":"test","pc_link":"","h5_link":"","pc_banner_img":null,"h5_banner_img":null,"sort":"0","status":0,"remark":"","create_time":"2020-06-17T20:10:23Z","version":0,"delete_flag":1},{"id":"223","name":"test","pc_link":"","h5_link":"","pc_banner_img":null,"h5_banner_img":null,"sort":"0","status":0,"remark":"","create_time":"2020-06-17T20:10:23Z","version":0,"delete_flag":1},{"id":"178","name":"test_insret","pc_link":"","h5_link":"","pc_banner_img":null,"h5_banner_img":null,"sort":"1","status":1,"remark":"","create_time":"2020-06-17T20:08:13Z","version":0,"delete_flag":1}]

事务支持

   async_std::task::block_on(async {
        let rb = Rbatis::new(MYSQL_URL).await.unwrap();
        let tx_id = "1";
        rb.begin(tx_id).await.unwrap();
        let v: serde_json::Value = rb.fetch(tx_id, "SELECT count(1) FROM biz_activity;").await.unwrap();
        println!("{}", v.clone());
        rb.commit(tx_id).await.unwrap();
    });

Web框架支持(这里举例hyper)


lazy_static! {
  static ref RB:Rbatis=async_std::task::block_on(async {
        Rbatis::new(MYSQL_URL).await.unwrap()
    });
}

use std::convert::Infallible;
async fn hello(_: hyper::Request<hyper::Body>) -> Result<hyper::Response<hyper::Body>, Infallible> {
    let v = RB.fetch("", "SELECT count(1) FROM biz_activity;").await;
    if v.is_ok() {
        let data: Value = v.unwrap();
        Ok(hyper::Response::new(hyper::Body::from(data.to_string())))
    } else {
        Ok(hyper::Response::new(hyper::Body::from(v.err().unwrap().to_string())))
    }
}

#[tokio::main]
#[test]
pub async fn test_hyper(){
    fast_log::log::init_log("requests.log",&RuntimeType::Std);
    // For every connection, we must make a `Service` to handle all
    // incoming HTTP requests on said connection.
    let make_svc = hyper::service::make_service_fn(|_conn| {
        // This is the `Service` that will handle the connection.
        // `service_fn` is a helper to convert a function that
        // returns a Response into a `Service`.
        async { Ok::<_, Infallible>(hyper::service::service_fn(hello)) }
    });
    let addr = ([0, 0, 0, 0], 8000).into();
    let server = hyper::Server::bind(&addr).serve(make_svc);
    println!("Listening on http://{}", addr);
    server.await.unwrap();
}

支持数据结构列表

数据库 已支持
Option
Vec
Slice
i32,i64,f32,f64,bool,String...more rust type
NativeDateTime
BigDecimal

支持数据库类型√已支持.进行中

数据库 已支持
Mysql
Postgres
Sqlite
TiDB
CockroachDB

进度表-按照顺序实现

功能 已支持
CRUD(内置CRUD模板(内置CRUD支持乐观锁/逻辑删除))
LogSystem(日志组件)
Tx(事务/事务嵌套/注解声明式事务)
Py(在SQL中使用和xml等价的类python语法)
SlowSqlCount(内置慢查询日志分析)
async/await支持
PagePlugin(分页插件)
LogicDelPlugin(逻辑删除插件)
DataBaseConvertPlugin(数据库表结构转换为配置插件) x
web(可视化Web UI) x

基准测试benchmark (测试平台 win10,6 core i7,16GB)

分步骤压测

//sql构建性能  Example_ActivityMapper.xml -> select_by_condition
操作/纳秒nano/op: 0.202 s,each:2020 nano/op
事务数/TPS: 495049.50495049503 TPS/s

//查询结果解码性能 decode/mysql_json_decoder  ->  bench_decode_mysql_json
操作/纳秒nano/op: 0.24 s,each:2400 nano/op
事务数/TPS: 416666.6666666667 TPS/s

//综合性能约等于
操作/纳秒nano/op:   4420 nano/op
事务数/TPS: 200000  TPS/s
  • 结论: 假设IO耗时为0的情况下,仅单线程 便有高达20万QPS/TPS,性能也是go语言版、java版 等等有GC暂停语言的 几倍以上性能

FAQ 常见问题

  • 日期时间和BigDecimal支持?
    已支持chrono::NaiveDateTime和bigdecimal::BigDecimal
  • async await支持?
    已同时支持async_std和tokio
  • postgres 的stmt使用$1,$2而不是mysql的?,那么是否需要特殊处理?
    不需要,因为rbatis 99%的api使用#{}描述参数变量,只需要写具体参数名称,不需要对应数据库的符号。
  • oracle数据库驱动支持?
    不支持,应该坚持去IOE
  • 直接使用驱动依赖项目里哪个库?
    应该使用rbatis-core, Cargo.toml 加入 rbatis-core = "*"
  • 如何选择运行时是tokio还是async_std?
# Cargo.toml 加入
rbatis-core = { features = ["runtime-async-std","all-type"]}
# 或者Cargo.toml 加入
# rbatis-core = { features = ["runtime-tokio","all-type"]}

和Rbatis相关项目

TODO 即将到来的特性
