BugStalker

Modern debugger for Linux x86-64. Written in Rust for Rust programs.

Table of Contents

• BugStalker
  • Supported rustc versions
  • Features
  • Installation
  • Start debugger session
  • Help
  • Start and restart
  • Stopping and continuing
    • Breakpoints
    • Watchpoints
    • Steps
    • Signals
  • Examining the stack
  • Examining source files
  • Examining data
  • Other commands
  • Tui interface
    • Configuration
  • Oracles
• Contributing

Supported rustc versions

• 1.75
• 1.76
• 1.77
• 1.78
• 1.79
• 1.80
• 1.81
• 1.82

Features

• written in rust for rust language with simplicity as a priority goal
• breakpoints, steps, signals, watchpoints
• multithreaded application support
• data query expressions
• support for a rust type system (collections, smart pointers, thread locals and many others), not only for printing but also for interaction
• two ui types: console and tui, switch available at any moment
• oracle as an extension mechanism
• builtin tokio oracle - like tokio_console but there is no need to make changes to the source codes
• and much more!

Installation

First check if the necessary dependencies (pkg-config and libunwind-dev) are installed:

For example, ubuntu/debian:

apt install pkg-config libunwind-dev

For example, fedora:

dnf install pkg-config libunwind-devel

Now install debugger:

cargo install bugstalker

That's all, bs command is available now!

cargo install bugstalker --no-default-features

Distro Packages

Arch Linux

pacman -S bugstalker

Nix package manager

There's flake which you can use to start using it. Just enable flakes then you're able to use it with:

nix run github:godzie44/BugStalker

bugstalker also provides a package which you can include to your NixOS config. For example:

{
  inputs = {
    nixpkgs.url = "github:nixos/nixpkgs/nixos-unstable";
    bugstalker.url = "github:godzie44/BugStalker";
  };

  outpus = {nixpkgs, bugstalker, ...}: {
    nixosConfigurations.your_hostname = nixpkgs.lib.nixosSystem {
      modules = [
        ({...}: {
          environment.systemPackages = [
            # assuming your system runs on a x86-64 cpu
            bugstalker.packages."x86_64-linux".default
          ];
        })
      ];
    };
  };
}

Home-Manager

There's a home-manager module which adds programs.bugstalker to your home-manager config. You can add it by doing the following:

{
  description = "NixOS configuration";

  inputs = {
    nixpkgs.url = "github:nixos/nixpkgs/nixos-unstable";
    home-manager.url = "github:nix-community/home-manager";
    home-manager.inputs.nixpkgs.follows = "nixpkgs";
    bugstalker.url = "github:godzie44/BugStalker";
  };

  outputs = inputs@{ nixpkgs, home-manager, bugstalker, ... }: {
    nixosConfigurations = {
      hostname = nixpkgs.lib.nixosSystem {
        system = "x86_64-linux";
        modules = [
          ./configuration.nix
          home-manager.nixosModules.home-manager
          {
            home-manager.sharedModules = [
              bugstalker.homeManagerModules.default
              ({...}: {
                programs.bugstalker = {
                  enable = true;
                  # the content of `keymap.toml`
                  keymap = {
                    common = {
                      up = ["k"];
                    }
                  };
                };
              })
            ];
          }
        ];
      };
    };
  };
}

Start debugger session

To start with program from binary file use:

bs my_cool_program

Or with arguments:

bs my_cool_program -- --arg1 val1 --arg2 val2

Or attach to program by its pid:

bs -p 123

Help

Print help for view all available commands.

Start and restart

demo

• run - start or restart a program (alias: r)

Stopping and continuing

The Debugger stops your program when breakpoints are hit, or after watchpoint are hit, or after steps commands, or when the OS signal is coming. BugStalker always stops the whole program, meaning that all threads are stopped. Thread witch initiated a stop become a current selected thread.

Continue execution

demo

• continue - resume a stopped program

Breakpoints

demo

• break {file}:{line} - set breakpoint at line (alias: b {file}:{line})
• break {function name} - set breakpoint at start of the function ( alias: b {function_name})
• break {instruction address} - set breakpoint at instruction ( alias: b {instruction address})
• break remove {number} - remove breakpoint by its number ( alias: b r {number})
• break remove {file}:{line} - remove breakpoint at line ( alias: b r {file}:{line})
• break remove {function name} - remove breakpoint at start of the function ( alias: b r {function name})
• break info - print all breakpoints

Watchpoints

demo

Watchpoint is a "data breakpoint". This means that the program stops when the variable (or expression, or just raw memory region) observed by watchpoint is changed. Currently, watchpoints feature based on x86-64 hardware breakpoints. Therefore, there are two limitations:

• only 4 watchpoints are possible at one time
• watchpoint "observe" memory region of 1/2/4/8 bytes size

You can set watchpoint at variables (global or locals), or at expression based on variables. Watchpoints for local variables will be removed automatically, when variable out of scope. If watchpoint observes a global variable, then it will live as long as the debugger is running.

Lets look at examples:

• watch my_var - stop when variable value is rewriting (alias: w my_var)
• watch +rw my_var - stop when variable value is reading or rewriting
• watch my_vector[0] - stop when first vector element is rewriting
• watch (~my_vector).len - stop when vector length is changed
• watch 0x100:4 - stop when writing to memory region [0x100:0x103]

Steps

demo

• stepi - step a single instruction
• step - step a program until it reaches a different source line ( alias: stepinto)
• next - step a program, stepping over subroutine (function) calls ( alias: stepover)
• finish - execute a program until selected stack frame returns ( alias: stepout)

Signals

demo

BugStalker will catch signals sent from OS to debugee program and stop execution. For example, try to send SIGINT (ctrl+c) to the debugee program to stop it.

Change current selected thread

demo

• thread info - print list with information about threads
• thread current - prints current selected thread
• thread switch {number} - switch selected thread

Examining the stack

When your program has stopped, the first thing you need to know is where it stopped and how it got there.

Each time your program performs a function call, the information about where in your program the call was made from is saved in a block of data called a stack frame. The frame also contains the arguments of the call and the local variables of the function that was called. All the stack frames are allocated in a region of memory called the call stack.

Stack frames

The call stack is divided up into contiguous pieces called stack frames. Each frame is the data associated with one call to one function. The frame contains the arguments given to the function, the function's local variables, and the address at which the function is executed.

Backtrace

demo

• backtrace - print backtrace of current stopped thread (alias: bt). Backtrace contains information about thread (number, pid, address of instruction where thread stopped) and all frames starting with the currently executing frame (frame zero), followed by its caller (frame one), and on up the stack.
• backtrace all - print backtraces of all active threads (alias: bt all).

Select a frame

demo

Most commands for examining the stack and other data in your program works on whichever stack frame is selected at the moment.

• frame info - print information about current selected frame.
• frame switch {num} - change current selected frame.

Examining source files

demo

BugStalker can print parts of your program's source code. When your program stops, the debugger spontaneously prints the line where it stopped. There is source commands for print more.

• source fn - print current selected function
• source {num} - print lines range [current_line-num; current_line+num]
• source asm - print assembly representation of current selected function

Examining data

demo

Of course, you need a way to examine data of your program.

• var {expression}|locals command for print local and global variables
• arg {expression}|all command for print a function arguments

These commands accept expressions as input or have a special mode (var locals print all local variables, args all print all arguments).

Expression

BugStalker has a special syntax for explore program data. You can dereference references, get structure fields, slice arrays or get elements from vectors by its index (and much more!).

Operator available in expressions:

• select variable by its name (ex. var a)
• dereference pointers/references/smart pointers (ex. var *ref_to_a)
• take a structure field (ex. var some_struct.some_field)
• take an element by index or key from arrays, slices, vectors, hashmaps ( ex. var arr[1] or even var hm[{a: 1, b: 2}])
• slice arrays, vectors, slices (ex. var some_vector[1..3] or var some_vector[1..])
• cast constant address to a pointer of a concrete type ( ex. var (*mut SomeType)0x123AABCD)
• take address (ex. var &some_struct.some_field)
• show canonic representation (for example, show vector header instead of vector data var ~myvec)
• parentheses for control an operator execution ordering

Write expressions is simple, and you can do it right now! Some examples:

• var *some_variable - dereference and print value of some_variable
• var hm[{a: 1, b: *}] - print value from hashmap corresponding to the key. Literal {a: 1, b: *} matches to any structure with field a equals to 1 and field b equals to any value
• var some_array[0][2..5] - print three elements, starts from index 2 from zero element of some_array
• var *some_array[0] - print dereferenced value of some_array[0]
• var &some_array[0] - print address of some_array[0]
• var (~some_vec).len - print len field from vector header
• var (*some_array)[0] - print a zero element of *some_array
• var *(*(var1.field1)).field2[1][2] - print dereferenced value of element at index 2 in element at index 1 at field field2 in dereferenced value of field field1 at variable var1 🤡

Other commands

Of course, the debugger provides many more commands:

• symbol {name or regex} - print symbol kind and address
• memory read {addr} - read debugged program memory (alias: mem read)
• memory write {addr} {value} - write into debugged program memory ( alias: mem write)
• register read {reg_name} - print value of register by name (x86_64 register name in lowercase) (alias: reg read)
• register write {reg_name} {value} - set new value to register by name ( alias: reg write)
• register info - print list of registers with it values (alias: reg info)
• sharedlib info - show list of shared libraries
• quit - exit the BugStalker (alias: q)

Tui interface

demo

One of the most funny BugStalker features is switching between old school terminal interface and pretty tui at any moment.

• tui - switch too terminal ui (in tui use Esc for switch back)

Configuration

There is a keymap.toml file with tui keybindings configuration. You can find the default configuration files at https://github.com/godzie44/BugStalker/tree/master/src/ui/tui/config/preset/keymap.toml.

To override any of the defaults, begin by creating the corresponding file (from the file linked above) to: ~/.config/bs/keymap.toml. You can change keybindings configuration file by exporting the KEYMAP_FILE environment variable.

Oracles

demo console

demo tui

Oracle is a module that expands the capabilities of the debugger. Oracles can monitor the internal state of a program to display interesting information. For example, tokio oracle is able to provide information about tokio runtime during program debugging without the need to change the source code. You must run the debugger with enabled oracle, for example, for tokio oracle:

bs --oracle tokio ...

Then use oracle command for view oracle information:

• oracle {oracle name} {subcommands} - run oracle (ex. oracle tokio)

Oracles also available in tui. Currently, there is only one builtin oracle - tokio oracle.

Contributing

Feel free to suggest changes, ask a question or implement a new feature. Any contributions are very welcome.

How to contribute.
