Dumb pipe
This is an example to use iroh-net to create a dumb pipe to connect two machines with a QUIC connection.
Iroh-net will take case of hole punching and NAT traversal whenever possible, and fall back to a relay if hole punching does not succeed.
It is also useful as a standalone tool for quick copy jobs.
This is inspired by the unix tool netcat. While netcat works with IP addresses, dumbpipe works with 256 bit node ids and therefore is somewhat location transparent. In addition, connections are encrypted using TLS.
Installation
cargo install dumbpipe
Examples
Use dumbpipe to stream video using ffmpeg / ffplay:
This is using standard input and output.
Sender side
On Mac OS:
ffmpeg -f avfoundation -r 30 -i "0" -pix_fmt yuv420p -f mpegts - | dumbpipe listen
On Linux:
ffmpeg -f v4l2 -i /dev/video0 -r 30 -preset ultrafast -vcodec libx264 -tune zerolatency -f mpegts - | dumbpipe listen
outputs ticket
Receiver side
dumbpipe connect nodeealvvv4nwa522qhznqrblv6jxcrgnvpapvakxw5i6mwltmm6ps2r4aicamaakdu5wtjasadei2qdfuqjadakqk3t2ieq | ffplay -f mpegts -fflags nobuffer -framedrop -
- Adjust the ffmpeg options according to your local platform and video capture devices.
- Use ticket from sender side
Forward development web server
You have a development webserver running on port 3000, and want to share it with a colleague in another office or on the other side of the world.
The web server
npm run dev
> - Local: http://localhost:3000
The dumbpipe listener
Listens on a magic endpoint and forwards all incoming requests to the dev web server that is listening on localhost on port 3000. Any number of connections can flow through a single dumb pipe, but they will be separate local tcp connections.
dumbpipe listen-tcp --host localhost:3000
This command will output a ticket that can be used to connect.
The dumbpipe connector
Listens on a tcp interface and port on the local machine. In this case on port 3001. Forwards all incoming connections to the magic endpoint given in the ticket.
dumbpipe connect-tcp --addr 0.0.0.0:3001 <ticket>
Testing it
You can now browse the website on port 3001.
Advanced features
Custom ALPNs
Dumbpipe has an expert feature to specify a custom ALPN string. You can use it to interact with existing iroh-net services.
E.g. here is how to interact with the iroh-bytes protocol:
echo request1.bin | dumbpipe connect <ticket> --custom-alpn utf8:/iroh-bytes/2 > response1.bin
if request1.bin contained a valid request for the /iroh-bytes/2
protocol, response1.bin will
now contain the response.
