Fork Union

The fork_union library is a thread-pool for "Fork-Join" SIMT-style parallelism for Rust and C++. It's quite different from most open-source thread-pool implementations, generally designed around heap-allocated "queues of tasks", synchronized by a "mutex". In C++, wrapping tasks into a std::function is expensive, as is growing the std::queue and locking the std::mutex under contention. Same for Rust. When you can avoid it - you should. OpenMP-like use-cases are the perfect example of that!

OpenMP, however, isn't great for fine-grained parallelism, when different pieces of your application logic need to work on different sets of threads. This is where fork_union comes in with a minimalistic STL implementation of a thread-pool, avoiding dynamic memory allocations and exceptions on the hot path, and prioritizing lock-free and CAS-free user-space "atomics" to system calls.

Usage

The fork_union supports just 2 operation modes:

• "Static" - even slicing for tasks with uniform cost.
• "Dynamic" - work-stealing for uneven workloads.

There is no nested parallelism, exception-handling, or "futures promises". Only 4 simple APIs:

• for_each_thread - to dispatch a callback per thread.
• for_each_static - for individual evenly-sized tasks.
• for_each_slice - for slices of evenly-sized tasks.
• for_each_dynamic - for individual unevenly-sized tasks.

Both are available in C++ and Rust.

Usage in Rust

A minimal example may look like this:

use fork_union::spawn;
let pool = spawn(2);
pool.for_each_thread(|thread_index| {
    println!("Hello from thread # {}", thread_index + 1);
});
pool.for_each_static(1000, |task_index| {
    println!("Running task {} of 3", task_index + 1);
});
pool.for_each_slice(1000, |first_index, count| {
    println!("Running slice [{}, {})", first_index, first_index + count);
});
pool.for_each_dynamic(1000, |task_index| {
    println!("Running dynamic task {} of 1000", task_index + 1);
});

A safer try_spawn_in interface is recommended, using the Allocator API. A more realistic example may look like this:

#![feature(allocator_api)]
use std::thread;
use std::error::Error;
use std::alloc::Global;
use fork_union::ForkUnion;

fn heavy_math(_: usize) {}

fn main() -> Result<(), Box<dyn Error>> {
    let pool = ForkUnion::try_spawn(4)?;
    let pool = ForkUnion::try_spawn_in(4, Global)?;
    let pool = ForkUnion::try_named_spawn("heavy-math", 4)?;
    let pool = ForkUnion::try_named_spawn_in("heavy-math", 4, Global)?;
    pool.for_each_dynamic(400, |i| {
        heavy_math(i);
    });
    Ok(())
}

Usage in C++

To integrate into your C++ project, either just copy the include/fork_union.hpp file into your project, add a Git submodule, or CMake. For a Git submodule, run:

git submodule add https://github.com/ashvardanian/fork_union.git extern/fork_union

Alternatively, using CMake:

FetchContent_Declare(
    fork_union
    GIT_REPOSITORY
    https://github.com/ashvardanian/fork_union
)
FetchContent_MakeAvailable(fork_union)
target_link_libraries(your_target PRIVATE fork_union::fork_union)

Then, include the header in your C++ code:

#include <fork_union.hpp>   // `fork_union_t`
#include <cstdio>           // `stderr`
#include <cstdlib>          // `EXIT_SUCCESS`

namespace fun = ashvardanian::fork_union;

int main() {
    fun::fork_union_t pool;
    if (!pool.try_spawn(std::thread::hardware_concurrency())) {
        std::fprintf(stderr, "Failed to fork the threads\n");
        return EXIT_FAILURE;
    }

    // Dispatch a callback to each thread in the pool
    pool.for_each_thread([&](std::size_t thread_index) noexcept {
        std::printf("Hello from thread # %zu (of %zu)\n", thread_index + 1, pool.count_threads());
    });

    // Execute 1000 tasks in parallel, expecting them to have comparable runtimes
    // and mostly co-locating subsequent tasks on the same thread. Analogous to:
    //
    //      #pragma omp parallel for schedule(static)
    //      for (int i = 0; i < 1000; ++i) { ... }
    //
    // You can also think about it as a shortcut for the `for_each_slice` + `for`.
    pool.for_each_static(1000, [](std::size_t task_index) noexcept {
        std::printf("Running task %zu of 3\n", task_index + 1);
    });
    pool.for_each_slice(1000, [](std::size_t first_index, std::size_t count) noexcept {
        std::printf("Running slice [%zu, %zu)\n", first_index, first_index + count);
    });

    // Like `for_each_static`, but each thread greedily steals tasks, without waiting for
    // the others or expecting individual tasks to have same runtimes. Analogous to:
    //
    //      #pragma omp parallel for schedule(dynamic, 1)
    //      for (int i = 0; i < 3; ++i) { ... }
    pool.for_each_dynamic(3, [](std::size_t task_index) noexcept {
        std::printf("Running dynamic task %zu of 1000\n", task_index + 1);
    });
    return EXIT_SUCCESS;
}

That's it.

Why Not Use $𝑋$

There are many other thread-pool implementations, that are more feature-rich, but have different limitations and design goals. Both in C++:

• taskflow/taskflow
• progschj/ThreadPool
• bshoshany/thread-pool
• vit-vit/CTPL
• mtrebi/thread-pool

... and in Rust:

• tokio-rs/tokio
• rayon-rs/rayon
• smol-rs/smol

Those are not designed for the same OpenMP-like use-cases as fork_union. Instead, they primarily focus on task queueing, which requires a lot more work.

Locks and Mutexes

Unlike the std::atomic, the std::mutex is a system call, and it can be expensive to acquire and release. Its implementations generally have 2 executable paths:

• the fast path, where the mutex is not contended, where it first tries to grab the mutex via a compare-and-swap operation, and if it succeeds, it returns immediately.
• the slow path, where the mutex is contended, and it has to go through the kernel to block the thread until the mutex is available.

On Linux, the latter translates to a "futex" syscall, which is expensive.

Memory Allocations

C++ has rich functionality for concurrent applications, like std::future, std::packaged_task, std::function, std::queue, std::conditional_variable, and so on. Most of those, I believe, aren't unusable in Big-Data applications, where you always operate in memory-constrained environments:

• The idea of raising a std::bad_alloc exception, when there is no memory left, and just hoping that someone up the call stack will catch it is simply not a great design idea for any Systems Engineering.
• The threat of having to synchronize ~200 physical CPU cores across 2-8 sockets, and potentially dozens of NUMA nodes around a shared global memory allocator, practically means you can't have predictable performance.

As we focus on a simpler concurrency parallelism model, we can avoid the complexity of allocating shared states, wrapping callbacks into some heap-allocated "tasks", and a lot of other boilerplate. Less work - more performance.

Atomics and CAS

Once you get to the lowest-level primitives on concurrency you end up with the std::atomic and a small set of hardware-supported atomic instructions. Hardware implements it differently:

• x86 is built around the "Total Store Order" (TSO) memory consistency model and provides LOCK variants of the ADD and CMPXCHG, which act as full-blown "fences" - no loads or stores can be reordered across it.
• Arm, on the other hand, has a "weak" memory model, and provides a set of atomic instructions that are not fences, that match C++ concurrency model, offering acquire, release, and acq_rel variants of each atomic instruction—such as LDADD, STADD, and CAS - which allow precise control over visibility and ordering, especially with the introduction of "Large System Extension" (LSE) instructions in Armv8.1.

In practice, a locked atomic on x86 requires the cache line in the Exclusive state in the requester's L1 cache. This will incur a coherence transaction (Read-for-Ownership) if some other core had the line. Both Intel and AMD handle this similarly.

It makes Arm and Power much more suitable for lock-free programming and concurrent data structures, but some observations hold for both platforms. Most importantly, "Compare and Swap" (CAS) is a very expensive operation, and should be avoided at all costs.

On x86, for example, the LOCK ADD can easily take 50 CPU cycles, being 50x slower than a regular ADD instruction, but still easily 5-10x faster than a LOCK CMPXCHG instruction. Once the contention rises, the gap naturally widens, and is further amplified by the increased "failure" rate of the CAS operation, when the value being compared has already changed. That's why for the "dynamic" mode, we resort to using an additional atomic variable as opposed to more typical CAS-based implementations.

Alignment

Assuming a thread-pool is a heavy object anyway, nobody will care if it's a bit larger than expected. That allows us to over-align the internal counters to std::max_align_t to avoid false sharing. In that case, even on x86, where the entire cache will be exclusively owned by a single thread, in eager mode, we end up effectively "pipelining" the execution, where one thread may be incrementing the "in-flight" counter, while the other is decrementing the "remaining" counter, and others are executing the loop body in-between.

Performance

The performance goal of Fork Union is to be comparable to OpenMP when running on a single NUMA node. In Parallel Reductions, on tiny inputs, it has the following performance:

$ PARALLEL_REDUCTIONS_LENGTH=1536 build_release/reduce_bench
----------------------------------------------------------------------------
Benchmark                 Time             CPU   Iterations UserCounters...
----------------------------------------------------------------------------
std::threads         2047275 ns      2008267 ns        13751 bytes/s=3.00106M/s
tf::taskflow          109782 ns       106764 ns       254660 bytes/s=76.2837M/s
av::fork_union         13136 ns        13136 ns      2117597 bytes/s=467.714M/s
openmp                 10494 ns        10256 ns      2848849 bytes/s=585.492M/s

Testing

To run the C++ tests, use CMake:

cmake -B build_release -D CMAKE_BUILD_TYPE=Release
cmake --build build_release --config Release
build_release/scripts/fork_union_test_cpp20

For C++ debug builds, consider using the VS Code debugger presets or the following commands:

cmake -B build_debug -D CMAKE_BUILD_TYPE=Debug
cmake --build build_debug --config Debug
build_debug/scripts/fork_union_test_cpp20

For Rust, use the following command:

rustup toolchain install nightly
cargo +nightly test --release
