crabapple

Crabapple is a Rust library for reading, inspecting, and extracting data from encrypted iOS backups created by Finder, Apple Devices, or iTunes.

⚠️ Warning ⚠️

This library is currently in an alpha state and should not be used in production code.

Features

• Load and parse the backup's Manifest.plist to obtain metadata, device info, and encryption parameters
• Derive encryption keys using PBKDF2 (HMAC-SHA256 then HMAC-SHA1) and unwrap protection class keys via AES Key Wrap (RFC 3394)
• Decrypt and query the AES-256 encrypted Manifest.db, exposing backup file metadata via rusqlite
• Retrieve and decrypt individual files by protection class (per-file AES-CBC with PKCS7 padding)
• Cross-platform support for macOS, Windows, and Linux

Installation

This library is available on crates.io.

Documentation

Documentation is available on docs.rs.

Quick Start

use std::{io::copy, fs::File};
use crabapple::{Backup, Authentication};

fn main() -> Result<(), Box<dyn std::error::Error>> {
    // Initialize a backup session for a device UDID with a password
    let udid_folder = "/Users/you/Library/Application Support/MobileSync/Backup/DEVICE_UDID";
    let auth = Authentication::Password("your_password".into());
    let backup = Backup::new(udid_folder, &auth)?;

    // List all files in the backup
    let entries = backup.get_backup_files_list()?;
    for entry in &entries {
        println!("{} - {}/{}", entry.file_id, entry.domain, entry.relative_path);
    }

    // Decrypt and read a file entry as a stream
    if let Some(entry) = entries.first() {
        let mut stream = backup.decrypt_entry_stream(&entry)?;
        // Write the stream to a file
        let mut file = File::create("decrypted.txt")?;
        copy(&mut stream, &mut file)?;
    }

    // Alternatively, decrypt and read a file entry into memory
    if let Some(entry) = entries.get(2) {
        let data = backup.decrypt_entry(&entry)?;
        println!("Decrypted {} ({} bytes)", entry.relative_path, data.len());
    }

    Ok(())
}

Getting Basic Device Information

You can retrieve device metadata (like device name, iOS version, and UDID) without opening the full backup database:

use std::path::Path;
use crabapple::get_device_basic_info;

fn main() -> Result<(), Box<dyn std::error::Error>> {
    let udid_folder = Path::new("/Users/you/Library/Application Support/MobileSync/Backup/DEVICE_UDID");
    let info = get_device_basic_info(udid_folder)?;
    println!("Device: {} (iOS {})", info.device_name, info.product_version);
    println!("UDID: {}", info.unique_device_id);
    Ok(())
}

Using a Pre-derived Key

If you have already derived the encryption key elsewhere, provide it directly:

use crabapple::{Backup, Authentication};

fn main() -> Result<(), Box<dyn std::error::Error>> {
    let udid_folder = "/path/to/backup";
    let hex_key = "abcdef0123456789...";
    let auth = Authentication::DerivedKey(hex_key.to_string());
    let backup = Backup::new(udid_folder, &auth)?;
    // ... proceed as normal
    Ok(())
}

Error Handling

crabapple uses a custom BackupError enum for error reporting. You can match on specific cases:

use crabapple::{Backup, Authentication, BackupError};

match Backup::new("/bad/path", &Authentication::Password("pass".into())) {
    Ok(b) => println!("Loaded backup successfully"),
    Err(BackupError::ManifestPlistNotFound(path)) => eprintln!("Missing Manifest.plist: {}", path),
    Err(err) => eprintln!("Error initializing backup: {}", err),
}
