Quill 🪶

A lightweight Rust plotting library for creating simple SVG 2D plots. Quill is designed for simplicity and ease of use, making it perfect for generating basic plots for reports, examples, or any application that needs clean, vector-based visualizations.

Features

• 🎨 Basic Styling: Choose colors, marker types, and line styles
• 📏 Simple Layouts: Configurable dimensions, titles, axis labels, legends, and grids
• 🔧 Builder Pattern: Clean API with method chaining
• 📈 Multiple Data Series: Support for multiple datasets on a single plot
• 🖼️ SVG Output: Export to SVG files or return as svg::Document for programmatic use
• 🖼️ PNG Support: Optional PNG output via png feature
• ⚡ Lightweight: Minimal dependencies for fast compilation

Quick Start

Add Quill to your Cargo.toml:

[dependencies]
quill = "0.1.0"

Basic Line Plot

use quill::*;

fn main() {
    let data = (0..=100).map(|x| {
        let xf = x as f64 * 0.1;
        (xf, xf.sin())
    }).collect();

    let plot = Plot::builder()
        .dimensions((600, 400))
        .title("Sine Wave")
        .x_label("X Axis")
        .y_label("Y Axis")
        .data([
            Series::builder()
                .name("sin(x)")
                .color("Blue")
                .data(data)
                .line(Line::Solid)
                .build(),
        ])
        .build();

    plot.to_svg("output.svg").unwrap();

    // Or get the SVG document for programmatic use
    let svg_doc = plot.to_document();
}

Examples

Line Plot

A simple sine wave visualization with connected points:

use quill::*;

let line_plot = Plot::builder()
    .dimensions((600, 400))
    .title("Line Graph Example")
    .x_label("X Axis")
    .y_label("Y Axis")
    .legend(Legend::TopRightOutside)
    .grid(Grid::Solid)
    .data([
        Series::builder()
            .name("Sine Curve")
            .color("Blue")
            .data(line_data())
            .marker(Marker::None)
            .line(Line::Solid)
            .build(),
    ])
    .build();

Scatter Plot

Data points without connecting lines:

use quill::*;

let scatter_plot = Plot::builder()
    .dimensions((600, 400))
    .title("Scatter Graph Example")
    .legend(Legend::TopRightOutside)
    .grid(Grid::Dashed)
    .data([
        Series::builder()
            .name("Lissajous Curve")
            .color("Red")
            .data(scatter_data())
            .marker(Marker::Circle)
            .marker_size(5.0)
            .line(Line::None)  // No connecting lines
            .build(),
    ])
    .build();

Multi-Series Plot

Multiple datasets on the same plot:

use quill::*;

let plot = Plot::builder()
    .dimensions((900, 500))
    .title("Sales Data")
    .x_label("Month")
    .y_label("Units Sold")
    .legend(Legend::TopLeftInside)
    .grid(Grid::Solid)
    .data([
        Series::builder()
            .name("Product A")
            .color("Blue")
            .data(product_a_data)
            .marker(Marker::Circle)
            .line(Line::Solid)
            .build(),
        Series::builder()
            .name("Product B")
            .color("Firebrick")
            .data(product_b_data)
            .marker(Marker::Square)
            .line(Line::Dotted)
            .build(),
        // Add more series as needed
    ])
    .build();

Investment Growth Data

Points with different line styles:

use quill::*;

let plot = Plot::builder()
    .dimensions((800, 600))
    .title("Hypothetical Investment Growth")
    .x_label("Years")
    .y_label("Value ($)")
    .x_range(Range::Manual { min: 0.0, max: 10.0 })
    .legend(Legend::TopLeftInside)
    .grid(Grid::Dotted)
    .font("Times New Roman")
    .data([
        Series::builder()
            .name("Low-Risk Investment")
            .color("Green")
            .data(low_risk_data)
            .marker(Marker::Circle)
            .line(Line::Solid)
            .build(),
        // Add more investment types
    ])
    .build();

API Overview

Plot Builder

Configure your plot with the builder pattern:

Plot::builder()
    .dimensions((width, height))           // Plot size
    .title("Plot Title")                   // Chart title
    .x_label("X Axis")                     // X-axis label
    .y_label("Y Axis")                     // Y-axis label
    .x_range(Range::Auto)                  // X-axis range (Auto or Manual)
    .y_range(Range::Auto)                  // Y-axis range (Auto or Manual)
    .legend(Legend::TopRightOutside)       // Legend position
    .grid(Grid::Solid)                     // Grid style
    .font("Arial")                         // Font family
    .margin(Margin::default())             // Plot margins
    .data([Series])                        // Data series
    .build()

Series Builder

Define data series with markers and line styling:

Series::builder()
    .name("Series Name")       // Legend name
    .color("Blue")             // Line/marker color
    .data(vec![(x, y)])        // Data points (f32, f64, i32, or i64 tuples)
    .marker(Marker::Circle)    // Point markers
    .marker_size(5.0)          // Marker size
    .line(Line::Solid)         // Line style (or Line::None for scatter)
    .build()

Note the Colors are derived from the pigment crate. More information at pigment.

Output Options

// Save to SVG file
plot.to_svg("output.svg").unwrap();

// Get SVG document for programmatic use
let svg_doc: svg::Document = plot.to_document();

Available Options

Markers

• Marker::None - No markers
• Marker::Circle - Circular points
• Marker::Square - Square points
• Marker::Cross - Cross markers

Line Styles

• Line::Solid - Solid lines
• Line::Dashed - Dashed lines
• Line::Dotted - Dotted lines
• Line::None - No connecting lines

Grid Styles

• Grid::Solid - Solid grid lines
• Grid::Dashed - Dashed grid lines
• Grid::Dotted - Dotted grid lines
• Grid::None - No grid

Legend Positions

• Legend::TopLeftInside
• Legend::TopRightInside
• Legend::TopRightOutside
• Legend::BottomLeftInside
• Legend::BottomRightInside
• Legend::BottomRightOutside
• Legend::LeftCenterInside
• Legend::RightCenterInside
• Legend::RightCenterOutside
• Legend::TopCenter
• Legend::BottomCenter
• Legend::None

Dependencies

Quill has minimal dependencies to keep your build fast:

• bon - For builder patterns
• pigment - For color handling
• svg - For SVG generation

License

This project is licensed under the Apache-2.0 License - see the LICENSE file for details.

Contributing

Contributions are welcome! Please feel free to submit issues, feature requests, or pull requests.
