The International Standard Atmosphere (ISA)

ISA Description

This model was implemented using the Manual of the ICAO Standard Atmosphere - extended to 80 kilometres / 262,500 feet (Doc 7488).

The manual provides standard values of atmospheric parameters in tabular form for levels up to 80 kilometres. It also gives values of constants and coefficients, as well as the underlying equations used in the calculation of the atmospheric parameters. The document is intended for use in calculations in the design of aircraft, in presenting test results of aircraft and their components under identical conditions, and in facilitating standardization in the development and calibration of instruments. Its use is also recommended in the processing of data from geophysical and meteorological observations. This manual intends to facilitate the uniform application of the ICAO Standard Atmosphere defined in Annex 8 — Airworthiness of Aircraft and provides sets of data that are accurate enough for practical applications (identical to ISO standard atmosphere).

Software Model Description

The software model follows the manual's approach to calculating temperature, pressure, and density. All features of the ISA are not currently implemented, although future iterations shall incorporate them, as well as common operations related to the ISA.

Goal

Accurately model the ISA, for use in multiple target applications.

Status

Actively in-development
[X] Temperature
[X] Pressure
[X] Density
[] Specific Weight
[] Pressure Scale
[] Number density
[] Mean particle speed
[] Mean free path
[] Collision Frequency
[] Speed of Sound
[] Dynamic Viscosity
[] Thermal Conductivity
[] Pressure, Temperature, Density Altitude

Implementation

Following the manual, relationships of the atmosphere are based on base temperatures, and base densities. These two values allow the calculation of base pressure. These base characteristics are accompanied by a lapse rate, which characterizes the change in temperature over a range of altitudes. The lapse rate allows variable temperatures, pressures, and densities to be calculated according to altitude.

Verification

Verification of the model was completed by manually extracting the data from the manual, for temperature and density. These two values were used to calculate pressures, following the approach in the manual. This was done as manually tabulating the altitude, temperature, and density columns took quite a long time. Below, you will find this models calculation comparison to the ISA geometric altitude tabulated temperature, density, and pressure (recalculated from temperature and density).

There are minute differences in temperature, density, and pressure. It is thought that this could be related to differences in floating point arithmetic and the fact that the original tabulated values were done from a Minsk-22 computer, who's floating point math was completed with nine decimal digits... An investigation is likely warranted, but a solution to this is likely impossible unless someone convinces the International Civil Aviation Organization to update their model! Or it is also likely there is model error.

History

The International Standard Atmosphere was originally calculated on the Minsk-22 Computer.

Warning

Thoroughly vet this library yourself before using in a real life application.
