hermes_rs

Note: Still a WIP - A PR is always welcome.

The API is subject to change as I iterate over use cases and improve the design.

A nearly dependency-free disassembler and assembler for the Hermes bytecode, written in Rust.

For the sake transparency, the current dependencies are:

sha1
- This is required for generating the footer hash.
serde - Optional
- So you can serialize/deserialize in your app
specta - Optional
- To generate TS types for tauri or wasm use cases
specta-util - Optional
- Same as above

A special thanks to P1sec for digging through the Hermes git repo, pulling all of the BytecodeDef files out, and tagging them. This made writing this tool much easier.

hermes_rs
Hermes Resources
Development
- Debugging Existing Functionality
- Supporting new versions of Hermes

Supported HBC Versions

HBC Version	Disassembler	(Binary) Assembler	(Textual) Assembler	Decompiler
89	✅	✅	❌	❌
90	✅	✅	❌	❌
93	✅	✅	❌	❌
94	✅	✅	❌	❌
95	✅	✅	❌	❌
96	✅	✅	❌	❌

A couple of features are missing currently, as they're low priority for me at the moment.

Regular Expression deserialization and serialization*
Debug Info deserialization and serialization*

* Supports u8 buffer for manual population

Known Issues & Weirdness

Slow(er) Performance on Large Files

Chances are you need to compile the program that uses this crate with the --release flag and run the binary directly.

HBC File Size Differences

The size of a binary produced with hermes_rs is going to be a bit larger than one compiled directly with hermes. This is primarily due to the fact that hermes does some string merging to keep bundles down.

Example: If car and racecar are both strings within the app, only racecar will be written. Two StringTableEntry objects are created: Entry { offset: 0, length: 7 } and Entry { offset: 4, length: 3 }.

As of right now, hermes_rs does not implement this functionality. It's pretty literal when it comes to strings, and doesn't try to be clever or save space.

Project Goals

Full coverage for all public HBC versions
The ability to inject code stubs directly into the .hbc file for instrumentation
Textual HBC assembly
Eventually a halfway decent decompiler, but that may be another project that uses this one as a base

Potential Use cases

Find which functions reference specific strings
Generate frida hooks for mobile implementations
- hermes loader -> hook loading the package -> feed to hermes_rs -> patch code for bidirectional communication or even just logging
Writing fuzzers

Features

Disassemble Hermes Bytecode (HBC)
Assemble Hermes Bytecode (HBC)
Type-safe instruction building across multiple versions of HBC
The ability to reduce binary size by only enabling certain versions of HBC
Utilities
- Dump Bytecode
  - cargo run --bin bytecode index.android.bundle
- Dump Strings
  - cargo run --bin strings index.android.bundle

Installation

To add hermes_rs to your project, simply run:

cargo add hermes_rs

Specific HBC Versions - enable any of ["v89","v90","v93","v94","v95", "v96"]
- Default: ["v94","v95", "v96"]
Serde Support (Optional) - enable the serde feature
Generate TS Types (Optional) - enable the specta feature
- cargo run --bin gen_ts --features specta will output *.d.ts to ./ts.
- Note: Only one HBC version can be used at a time for this due to a limitiation in specta.

Usage

Reading File Header

let filename = "./input_data/index.android.bundle";

let f = File::open(filename).expect("no file found");
let mut reader = io::BufReader::new(f);

let mut hermes_file = HermesFile::deserialize(&mut reader);

println!("{:?}", hermes_file.header);

Output:

HermesHeader {
  magic: 2240826417119764422,
  version: 94,
  sha1: [20, 178, 139, 133, 105, 198, 134, 29, 58, 101, 194, 248, 210, 173, 84, 79, 162, 174, 43, 205],
  file_length: 11059884,
  global_code_index: 0,
  function_count: 54483,
  string_kind_count: 3,
  identifier_count: 35878,
  string_count: 65091,
  overflow_string_count: 425,
  string_storage_size: 2238216,
  big_int_count: 0,
  big_int_storage_size: 0,
  reg_exp_count: 448,
  reg_exp_storage_size: 49719,
  array_buffer_size: 132510,
  obj_key_buffer_size: 43517,
  obj_value_buffer_size: 137207,
  segment_id: 0,
  cjs_module_count: 0,
  cjs_module_offset: 0,
  function_source_count: 1361,
  debug_info_offset: 11059836,
  options: BytecodeOptions {
    static_builtins: false,
    cjs_modules_statically_resolved: false,
    has_async: false,
    flags: false
  },
}

Reading Strings

println!("Strings: {:?}", hermes_file.get_strings());

Output:

Strings: ["$$typeof", "type", "API", "isArray", "Array", ... ]

Reading Function Headers

for func in hermes_file.function_headers {
    println!("{:?}", func);
}

// Prints the following:
Small(SmallFunctionHeader { offset: 252641, param_count: 3, byte_size: 63, func_name: 5168, info_offset: 842244, frame_size: 16, env_size: 0, highest_read_cache_index: 1, highest_write_cache_index: 0, flags: FunctionHeaderFlag { prohibit_invoke: ProhibitNone, strict_mode: false, has_exception_handler: false, has_debug_info: false, overflowed: false }, exception_handlers: [], debug_info: None })
Small(LargeFunctionHeader { offset: 252704, param_count: 2, byte_size: 41, func_name: 3756, info_offset: 842244, frame_size: 14, env_size: 0, highest_read_cache_index: 1, highest_write_cache_index: 0, flags: FunctionHeaderFlag { prohibit_invoke: ProhibitNone, strict_mode: false, has_exception_handler: false, has_debug_info: false, overflowed: false }, exception_handlers: [], debug_info: None })
...

Dumping Bytecode

Single Function

Call print_bytecode_for_fn(fidx), where fidx is the function index of the element in hermes_file.function_headers.

hermes_file.parse_bytecode_for_fn(1337);

Output:

Function<setCurrentTarget>(3 params, 11 registers, 0 symbols):
0x00000000	GetEnvironment  r0,  0
0x00000001	LoadFromEnvironment  r2,  r0,  6
0x00000002	LoadConstUndefined  r0
0x00000003	LoadParam  r1,  1
0x00000004	Call2  r2,  r2,  r0,  r1
0x00000005	LoadConstNull  r1
0x00000006	PutById  r2,  r1,  1,  "currentTarget"
0x00000007	Ret  r0

Entire File

Printing out the bytecode for the entire executable in a human-readable format is possible by calling print_bytecode.

hermes_file.print_bytecode();

Which outputs:

Function<global>(1 params, 19 registers, 0 symbols):
0x00000000	DeclareGlobalVar  "__BUNDLE_START_TIME__"
0x00000001	DeclareGlobalVar  "__DEV__"
0x00000002	DeclareGlobalVar  "process"
0x00000003	DeclareGlobalVar  "__METRO_GLOBAL_PREFIX__"
0x00000004	CreateEnvironment  r3
0x00000005	LoadThisNS  r4
0x00000006	GetById  r1,  r4,  1,  "nativePerformanceNow"
0x00000007	GetGlobalObject  r0
0x00000008	JmpTrue  2L1,  r1
0x00000009	TryGetById  r2,  r0,  2,  "Date"
0x0000000A	GetByIdShort  r1,  r2,  3,  "now"
0x0000000B	Call1  r1,  r1,  r2
0x0000000C	Jmp  L1
0x0000000D	TryGetById  r5,  r0,  1,  "nativePerformanceNow"
    L1:
0x0000000E	LoadConstUndefined  r2
0x0000000F	Call1  r1,  r5,  r2
0x00000010	PutById  r0,  r1,  1,  "__BUNDLE_START_TIME__"
0x00000011	LoadConstFalse  r1
0x00000012	PutById  r0,  r1,  2,  "__DEV__"
0x00000013	GetByIdShort  r1,  r4,  4,  "process"
0x00000014	JmpTrue  5,  r1
...

Raw Bytes

In the event that you want to access just the raw bytes for a specific function, you can use hermes_file.get_bytecode() and iterate. The function returns a Vec<FunctionBytecode>, which has the function index and bytecode (Vec<u8>) pairing.

let bc = hermes_file.get_bytecode();

for func in bc {
  println!("{:?}", func);
}

Output:

FunctionBytecode { func_index: 0, bytecode: [52, 2, 11, 0, 0, 52, 3, 11, 0, 0, 52, 217, 0, 0, 0, 52, ..<truncated>... ] }
FunctionBytecode { func_index: 1, bytecode: [50, 2, 108, 8, 1, 42, 2, 0, 8, 100, 7, 2, 2, 0, 100, 4, ..<truncated>... ] }
FunctionBytecode { func_index: 2, bytecode: [48, 0, 57, 0, 0, 1, 19, 0, 54, 1, 0, 2, 219, 106, 1, 1, ..<truncated>... ] }
FunctionBytecode { func_index: 3, bytecode: [108, 3, 2, 41, 0, 0, 46, 2, 0, 1, 54, 1, 2, 1, 163, 83, ..<truncated>... ] }
FunctionBytecode { func_index: 4, bytecode: [108, 3, 1, 41, 0, 0, 46, 2, 0, 1, 54, 1, 2, 1, 47, 83,  ..<truncated>... ] }
FunctionBytecode { func_index: 5, bytecode: [108, 4, 1, 41, 2, 0, 46, 1, 2, 1, 54, 0, 1, 1, 47, 83,  ..<truncated>... ] }
FunctionBytecode { func_index: 6, bytecode: [108, 4, 1, 41, 2, 0, 46, 1, 2, 1, 54, 0, 1, 1, 47, 83,  ..<truncated>... ] }

Encoding Instructions

Encoding instructions is trivial - each Instruction implements a trait with deserialize and serialize methods.

use hermes_rs::{define_instructions, InstructionParser};

/*
 * Use the define_instructions macro to get a vec of the correct instructions
 * for the version of Hermes you're targeting.
 * The first parameter is the hermes version you'd like to use.
 *
 * The bytecode below represents: eval(`print(123);`)
 * The `print(123)` string is the second (index 1) string in the string table.
*/
let instructions = define_instructions!(
    hermes_rs::v96,
    LoadConstString { r0: 0.into(), p0: 1.into() },   // Load `print(123);` into r0
    DirectEval { r0: 0.into(), r1: 0.into(), p0: 0.into() }, // Evaluate the string
    Ret { r0: 0.into() },                      // Return
).unwrap();

let mut writer = Vec::new();

for instr in instructions {
    instr.serialize(&mut writer);
}

// Make sure the encoded bytes are valid
assert!(writer == vec![115, 0, 1, 0, 94, 0, 0, 0, 92, 0], "Bytecode is incorrect!");

Creating Binaries From Scratch

Take a look at the Creating Binaries example.

Working example: cargo run --example create

Using specific HBC Versions

Want to use a specific version of the Hermes bytecode and reduce your binary size?

In Cargo.toml, find the hermes_rs dependency and select which HBC version(s) you'd like to use in your application.

Example:

[dependencies]
hermes_rs = { features = ["v89", "v90", "v93", "v94", "v95", "v96"] }

Hermes Resources

My Stuff

Github.io Page: https://pilfer.github.io/mobile-reverse-engineering/react-native/

Other Resources

Official docs: https://hermesengine.dev/
- Source: https://github.com/facebook/hermes
hermes-dec disassembler/decompiler:
- https://github.com/P1sec/hermes-dec
- Opcode Docs: https://p1sec.github.io/hermes-dec/opcodes_table.html
hbctool: https://github.com/bongtrop/hbctool
hasmer: https://github.com/lucasbaizer2/hasmer

Development

Debugging Existing Functionality

My code isn't perfect, and this project is a fairly large undertaking. Because of this, you may run into some bugs. Aside from using an actual debugger with this project, the best tool to use for inspecting Hermes Bytecode files is ImHex by WerWolv.

It features an expressive pattern language that allows you to visualize binary structures with ease.

I've included a scratchpad pattern to speed things up. It isn't 1:1 with this repository, but it's close enough to inspect most bits of memory to identify where things may be going wrong and why.

If you need something more verbose that includes examples of instructions, see: https://github.com/Pilfer/hermes-imhex-pattern/. Please note that parts of that file are wrong and you may need to do some hevay lifting or code generation to support the HBC version you're targeting.

Supporting new versions of Hermes

This section assumes that only instructions have been modified, and not core parsing logic (struct fields, RegExp bytecode, Debug Info fields, etc). If the latter has a diff, obviously we'll need to implement those changes.

There is a script in ./def_versions/_gen_macros.js that reads and parses a Bytecode Definition file passed to it as the first argument and outputs a file containing the macro body to support the updated instructions.

# How I generated them

cd ./def_versions

node _gen_macros.js 89.def > ../src/hermes/v89/mod.rs
node _gen_macros.js 90.def > ../src/hermes/v90/mod.rs
node _gen_macros.js 93.def > ../src/hermes/v93/mod.rs
node _gen_macros.js 94.def > ../src/hermes/v94/mod.rs
node _gen_macros.js 95.def > ../src/hermes/v95/mod.rs

Example with a hypothetical v100 version :

node _gen_macros.js v100.def

Which outputs:

use crate::hermes;

build_instructions!(
  (0, Unreachable, ),
  (1, NewObjectWithBuffer, r0: Reg8, p0: UInt16, p1: UInt16, p2: UInt16, p3: UInt16),
  (2, NewObjectWithBufferLong, r0: Reg8, p0: UInt16, p1: UInt16, p2: UInt32, p3: UInt32),
  (3, NewObject, r0: Reg8),
  (4, NewObjectWithParent, r0: Reg8, r1: Reg8),
  ... other instructions here
);

From here, you'll add a new directory and mod.rs file for this version (./src/hermes/v100/mod.rs) and paste the output from the script into it.

This could (and probably should) be a build.rs process.

After creating this file, open up ./src/hermes/mod.rs and navigate to the Instruction module imports and add the import, then populate the Instruction enum + trait + other functions' match statements with the new version. You'll likely need to rely on the compiler to complain about missing match branches - there's only a few, though.

As this codebase evolves, you may need add branch arms in different matches.

#[macro_use]
#[cfg(feature = "v100")]
pub mod v100;

// ...

pub enum HermesInstruction {
  // ...
  #[cfg(feature = "v100")]
  V100(v100::Instruction),
}

// ...

impl HermesInstruction {
  // implement the methods of the trait
  fn display(&self, _hermes: &HermesHeader) -> String{
      match self {
        // ...
        #[cfg(feature = "v100")]
        HermesInstruction::V100(instruction) => instruction.display(_hermes),
      }
  }

  fn size(&self) -> usize {
      match self {
          // ...
          #[cfg(feature = "v100")]
          HermesInstruction::V100(instruction) => instruction.size(),
      }
  }
}


// ...

// In parse_bytecode there's currently a match statement that will also need to be populated...
let ins_obj: Option<HermesInstruction> = match self.version {
  #[cfg(feature = "v89")]
  89 => Some(HermesInstruction::V89(v89::Instruction::deserialize(&mut r_cursor, op))),
  #[cfg(feature = "v90")]
  90 => Some(HermesInstruction::V90(v90::Instruction::deserialize(&mut r_cursor, op))),
  #[cfg(feature = "v93")]
  93 => Some(HermesInstruction::V93(v93::Instruction::deserialize(&mut r_cursor, op))),
  #[cfg(feature = "v94")]
  94 => Some(HermesInstruction::V94(v94::Instruction::deserialize(&mut r_cursor, op))),
  #[cfg(feature = "v95")]
  95 => Some(HermesInstruction::V95(v95::Instruction::deserialize(&mut r_cursor, op))),
  _ => None,
};

Finally, add the feature (v100 = []) to Cargo.toml.

Dependencies

~320–730KB
~16K SLoC

HBC Version	Disassembler	(Binary) Assembler	(Textual) Assembler	Decompiler
89	✅	✅	❌	❌
90	✅	✅	❌	❌
93	✅	✅	❌	❌
94	✅	✅	❌	❌
95	✅	✅	❌	❌
96	✅	✅	❌	❌

HBC Version	Disassembler	(Binary) Assembler	(Textual) Assembler	Decompiler
89	✅	✅	❌	❌
90	✅	✅	❌	❌
93	✅	✅	❌	❌
94	✅	✅	❌	❌
95	✅	✅	❌	❌
96	✅	✅	❌	❌

HBC Version	Disassembler	(Binary) Assembler	(Textual) Assembler	Decompiler
89	✅	✅	❌	❌
90	✅	✅	❌	❌
93	✅	✅	❌	❌
94	✅	✅	❌	❌
95	✅	✅	❌	❌
96	✅	✅	❌	❌
