AKAS: API Key Authorization Server

A simple and higth performance server to authorized HTTP requests by API key checks.

• A hight performance server written in Rust.
• In-memory keys storage.
• Control authorization bearer with pre-checks.

Authorization: Bearer <key>

The file of the list of the keys to be used for authorization should contain one key per line in plain or SHA-256 format:

• sha256 (default)

8b89600015b273c28f966f368456e45e01df239a36bf939ff72a16881f775679
fb22be500af1ef0479745bbbce847854da33f5e910361ad278e0282995b95f4d
...

• plain

mykey-3532dceb-f38a-491b-814d-9607bc9a947a
mykey-c2d79a40-388e-4709-9e4b-903035b0e71e
...

Usage

$ ./akas --help
A HTTP API key-Based Authorization Server

Usage: akas <COMMAND>

Commands:
  serve  Start the server
  load   Load keys from file
  help   Print this message or the help of the given subcommand(s)

Options:
  -h, --help     Print help
  -V, --version  Print version

$./akas serve --help
Start the server

Usage: akas serve [OPTIONS]

Options:
      --admin-key <ADMIN_KEY>  Admin key for /load and /status URI [env: AKAS_ADMIN_KEY=] [default: ]
      --no-admin-key           No admin key flag
  -p, --port <PORT>            Port of the server [env: AKAS_PORT=] [default: 5001]
      --log-level <LOG_LEVEL>  Log level <error|warn|info|debug|trace> - default info [env: AKAS_LOG_LEVEL=] [default: info]
      --length <LENGTH>        Length of the key [optional] [env: AKAS_LENGTH=] [default: 0]
      --prefix <PREFIX>        Prefix of the key [optional] [env: AKAS_PREFIX=] [default: ]
  -h, --help                   Print help

Start akas server with the default port 5001

./akas serve --admin-key my-admin-key

Example of configuration of a Nginx server

server {
    listen     80;
    server_name _;

    location / {
      auth_request     /auth;
      auth_request_set $auth_status $upstream_status;
      root             /usr/share/nginx/html;
      index            index.html index.htm;
    }

    location = /auth {
      internal;
      proxy_pass              http://localhost:5001/auth;
      proxy_pass_request_body off;
      proxy_set_header        content-length         "";
      proxy_set_header        x-forwarded-for        $proxy_add_x_forwarded_for;
      proxy_set_header        x-original-host        $host;
      proxy_set_header        x-original-uri         $request_uri;
      proxy_set_header        x-original-remote-addr $remote_addr;
    }
}

More details of Nginx configuration can be found in the configuring subrequest authentication documentation

• Authorized request: curl -H "Authorization: Bearer <key>" http://<host>/

Endpoints URIs

/auth: Authorization endpoint

If the API key is present in the hashset return 200 OK, otherwise return 401 Unauthorized.

/load

Load new plain/hash keys file and replace the current keys in HashSet. The access is protected by an optional admin key. Example of a curl request:

curl -v \
  -H "Authorization: Bearer my-admin-key" \
  --url http://localhost:5001/load \
  -F 'json={"format": "sha256", "hash_input_file": "43fcba0b3a ..."};type=application/json' \
  -F file=@./tests/files/sha256_key.txt

If the server is started without an admin key (--no-admin-key), the header Authorization: Bearer is still required with a fake key.

/status

Return the application state in JSON format. The access is protected by an optional admin key. Example:

{
    "log_level": "INFO",
    "file_hash": "43fcba0b3a5ab1b302f9d13617ae4eec6ae623a7fd52437dd992d5dca115e68d",
    "file_date": "2024-11-09T14:07:23.416999558+00:00",
    "file_key_count": 150,
    "length": 42,
    "prefix": "mykey-"
}

Example of request:

curl -v  \
  -H "Authorization: Bearer my-admin-key" \
  http://localhost:5001/status

If the server is started without an admin key (--no-admin-key), the header Authorization: Bearer is still required with a fake key.

/auth-ok

Always return 200 OK without checking the key (mainly for testing purposes).

/auth-unauthorized

Always return 401 Unauthorized without checking the key (for testing purposes or disable access).

Features & Limitations

• Authorization by HTTP Bearer key.
• Configuration:
  • via command line arguments.
  • via environment variables.
• Subcommand serve: Start server
• Subcommand load: Load file
• Subcommand status: Get Hash of input file, datetime of load, number of valid keys.
• load plain keys file (plain text) by curl.
• load hash keys file (hashed - sha256) by curl.
• Plain or hashed keys loaded and saved in a Rust HashSet for a fast authorization check.
• Check of the key format during the loading process of the file based keys storage:
  • prefix and length for plain keys file.
  • SHA-256 for hashed keys file.
• Initial check of the input key format in the header (length and prefix) [optional].
• Endpoints:
  • /auth: default endpoint.
  • /load: Load new plain/hash keys file.
  • /status: Get Hash of input file, datetime of load, number of valid keys.
  • /auth-ok: always return 200 OK without checking the key.
  • /auth-unauthorized: always return 401 Unauthorized without checking the key.
• Admin key in header bearer for /load and /status.
• Binaries compatibility for Linux with no dependencies:
  • x86-64 and arm64.
  • glibc (debian, ubuntu, fedora...) and musl libc (alpine ...).
• Tests:
  • Unit tests (Rust).
  • Functional tests (Robot Framework).
• Gitlab CI/CD Pipeline to auto-publish new versions.
• Renovate Bot auto-update dependencies.
• AKAS packaged in a distroless Docker image.
• Log implemenations with https://crates.io/crates/tracing-actix-web
• Log requests:
  • All requests: Level Info
  • Only unauthorized requests (401): Level Warn
• Cache implementation for faster access to key authorization without SHA-256 operation (LRU Cache).

Installation

• Binary file installation on Linux via the GitLab package registry of the project:

  • 2 architectures:
    • akas-x86_64-linux-<gnu|musl>.tar.gz : x86_64 (Intel, AMD).
    • akas-aarch64-linux-<gnu|musl>.tar.gz : arm64
  • 2 C standard library with no dependencies:
    • akas-<x86_64|aarch64>-linux-gnu.tar.gz : glibc for Debian, Ubuntu, Fedora...
    • akas-<x86_64|aarch64>-linux-musl.tar.gz : musl libc for Alpine

• With a Rust environment, running this command will globally install the akas binary:

cargo install akas

Log

The level of log is set with the RUST_LOG environment variable:

• error - Requests are not logged.
• warn - Only unauthorized requests (401) are logged.
• info (default) - all requests are logged.
• debug
• trace
• off

Access log default format

2024-11-01T09:26:17.455655Z  WARN HTTP request{http.method=GET http.route=/auth http.flavor=1.1 http.scheme=http http.host=localhost:5001 http.client_ip=127.0.0.1 http.user_agent=curl/7.88.1 http.target=/auth otel.name=GET /auth otel.kind="server" request_id=f8cb807d-666d-457a-957b-26b36ccb1a0f}: akas: sha256_key: f0755926b82353d817f2ca1011fd98179472c2df0fed2225580714d8ad09e336 - unknown-host - unknown-uri - access unauthorized
2024-11-01T09Z:26:20.182590Z  INFO HTTP request{http.method=GET http.route=/auth http.flavor=1.1 http.scheme=http http.host=localhost:5001 http.client_ip=127.0.0.1 http.user_agent=curl/7.88.1 http.target=/auth otel.name=GET /auth otel.kind="server" request_id=97199511-7f08-4ee4-b4fa-71d7e669cfe2}: akas: sha256_key: 92c55f4d88b1 - unknown-host - unknown-uri - access authorized

More details:

• Env logger
• tracing-actix-web

Development

• Clone the source repository: git clone https://gitlab.com/op_so/projects/akas.git

• To format and lint:

cargo fmt  # cargo fmt -- --check
cargo clippy

• To test:

cargo test
cargo tarpaulin --ignore-tests
cargo audit

• To run: cargo run -- --file tests/files/plain_key.txt

• To build:

cargo build            # Debug binary target/debug/akas
cargo build --release  # Release binary target/release/akas

Authors

• FX Soubirou - Initial work - GitLab repositories

License

This program is free software: you can redistribute it and/or modify it under the terms of the MIT License (MIT). See the LICENSE for details.
